23.8Inch Lcd Media Player

High BrightnessWith a great brightness of max 5,000 cd/㎡ , the KT
Send Inquiry
Description
Argument
Products Description
43inch Optical Bonding Display(图1)
  •

32px;">

High Brightness
With a great brightness of max 5,000 cd/㎡ , the KT series clearly delivers contents and attracts public attention, which is the ultimate display for outdoor visibility.

  •



Long Lasting Brightness
Visible with Polarized Sunglasses
By adding more LED units, KT series    operates brighter at a lower temperature,  thereby lasting longer than conventional products.
43inch Optical Bonding Display(图2)
43inch Optical Bonding Display(图3)
  •




High Temperature LCD
Work normally in direct sunlight. Combined with a high Tni110℃ industrial grade OC, the KT series can operate 24/7.

  •




Slim Design
Thanks to its thin depth, the KT          series takes up less space, which   leads to space efficiency and mounting friendly in any Outdoor Signage cabinet or enclosure.
43inch Optical Bonding Display(图4)
43inch Optical Bonding Display(图5)
  •


Smart Brightness     Control
The auto brightness sensor and preset time scheduler save power consumption and protect viewer's eyes by adjusting the brightness automatically according to the embient brightness.

  •


Support Multi-
Input Method

KT Series adopt built-in industrial grade PSU and AD board with multi-input interface support HDMI, VGA, DVI, DP, USB, RS232 which allows “plug and play”.

43inch Optical Bonding Display(图6)


Tags: 23.8 inch hight bright player 23.8 lcd media player LCD Digital Menu Boards

Technical parameter
65 inch High Bright Outdoor E-

65 inch High Bright Outdoor E-

Intelligent Runway Digital Sig

Intelligent Runway Digital Sig

Intelligent Runway System

Intelligent Runway System

MacDonald LCD Digital Menu Boa

MacDonald LCD Digital Menu Boa





Items
Specification
Unit
Note
Active Screen Size
23.8
inch
Diagonal
Display Area
527.04(H)x296.46(V)
mm

Outline Dimension
549.84(H)x323.56(V)x39.50(D)
mm

Driver Element
a-Si TFT active matrix


Display Colors
16.7M
colors

Color Gamut
72
%
NTSC
Number of Pixels
1920*1080
Pixel

Pixel Arrangement
RGB vertical stripe


Pixel Pitch
0.2745(H)x0.2745(V)
mm

Surface Treatment
Haze 25%,3H


Brightness
1500
nits

Power
60
W

Zoom
16:09


Working temperature
0--50

Weight
4
kg

Backlight life
50000
hr
